A–10 16021520 Rev. 0 ©2002 Maytag Appliances Company
Numbered Pads Display Options (Factory Settings in Bold)
1
End of Cycle Beep
OP:10
OP:11
OP:12
3 second continuous beep.
Continuous beep until door is opened.
5 beeps bursts until door is opened.
2
Speaker Volume
(Not Available on
RCS10)
OP:20
OP:21
OP:22
OP:23
Speaker off, no beep sounds.
Sets volume to low.
Sets volume to medium.
Sets volume to high.
3
Key Beep
OP:30
OP:31
No beep when pad is pressed.
Sound beep when pad is pressed.
4
Keyboard Enable
Window
OP:40
OP:41
OP:42
OP:43
15 seconds after oven door is opened, keyboard disabled
30 seconds after oven door is opened, keyboard disabled
1 minute after oven door is opened, keyboard disabled
2 minutes after oven door is opened, keyboard disabled
5
Add Time during
Heating
OP:50
OP:51
Prevents adding heating time while oven is heating.
Allows heating time to be changed while oven is heating when a
memory pad is pressed.
6
Reset Door Open
OP:60
OP:61
Allows oven to resume heating time countdown after door is
opened during cycle.
Cancels heating time count down when door is opened during cycle.
7
Maximum Heating Time
(Not Available on
RCS10)
OP:70
OP:71
Allows 60 minutes of heating time.
Allows 10 minutes of heating time.
8
Manual Operation
OP:80
OP:81
Allows use of preprogrammed pads only.
Allows use of manual time entry and preprogrammed pads.
9
Double Digit Operation
(Not Available on
RCS10, RCS10MP,
and RCS10MPS)
OP:90
OP:91
Allows 10 (09) preprogrammed pads.
Allows 100 (0099) preprogrammed pads.
START
STOP
RESET
3. Press 9 pad.
See table below for options.
Displays shows “OP:91”.
“OP” represents optional program
mode, first number represents option
number and second number represents
functions currently selected for option.
4. Press 9 pad repeatedly to change
setting.
5. Press START pad to save changes.
Repeat steps 3–5 to change additional
options.
Changes appear after door is closed or STOP/
RESET is pressed.
6. Press STOP/RESET pad or close oven door to exit
programming mode.
2
9
User Options
Follow the instructions below to customize oven
operation. End-of-cycle signal, maximum cooking time
and other options can be changed to meet your cooking
needs. Example: Change setting to single digit pad
operation.
1. Open oven door.
If door is closed or RESET pad is pressed before
finishing programming sequence, oven exits
programming mode.
2. Press and hold pad 2 for approximately 5
seconds.
After 5 seconds, signal sounds.
Display shows “0P:”.
