1-10 Product Description
1.3.6 Bottom Components
The bottom external components are shown in Figure 1-7 and are described in
Table 1-6.
Figure 1-7. Bottom Components
Table 1-6
Computer Components
Bottom
Item Component Function
1 Modem compartment Integrated modem (selected models)
2 Docking latch receptacles Locks computer to optional convenience base
3 Docking alignment guide Aligns computer to optional convenience base
4 Tilt feet Adjusts computer to an angle
5 MultiBay screw Secures MultiBay Devices
6 Hard drive cover Covers hard drive compartment
* Hard drive security screw Secures hard drive cover (not shown)
