Hewlett-Packard Pavilion t700 - Desktop PC Technical Specifications

Download Technical specifications of HP Pavilion t700 - Desktop PC Adapter, Desktop for Free or View it Online on All-Guides.com.

HP Pavilion t700 - Desktop PC Technical specifications - Page 1
1
Technical Specifications
Model t760a PL398AA
Processor & Speed Intel® Pentium® 4(P)540 Processor – 3.2GHz/800HT
LGA775
Chipset Intel® 915P
Motherboard Puffer-UL8E (PTGD1-LA)
RAM 512/3200 MB 400 DDR SDRAM
Maximum 3 GB
Sockets Four 184-pin DDR DIMMs
Size 128, 256, 512 AND 1024 MB DDR DIMMs
Free DIMM Sockets Three
Pairs Required No
Type Supported JEDEC unbuffered DDR SDRAM DIMM specification
Cache 16KB Data Cache + Trace Cache L1, 1MB L2 Integrated
on Processor module
Hard Drive 160 GB (7200 RPM) SATA
Optical Drive 8x DVD(+/-)R/RW DL Drive
Transfer rates
Write: Up to 40x (CD-R)
Write: Up to 24x (CD-RW)
Write: Up to 8x (DVD(+/-)R)
Write: Up to 4x (DVD(+/-)RW)
Write: Up to 2.4x (DVD+R DL)
Read: Up to 40x (CD)
Read: Up to 12x (DVD)
Diskette Drive None
9 in 1 Card Reader Compact Flash I/II, Memory Stick/PRO, MMC/SD, Smart
Media, xD, Microdrive
Fax/Data Modem V.90 56Kbps
Fax Speed Up to 14.4Kbps
Data Compression V.42 bis
Error Correction V .42
EIA Fax Commands Class 1
Video Graphics PCI Express 16x Graphics Card
Controller ATI RV370E
Video Memory 128 MB DDR, not upgradeable
Video Connectors Composite & S-Video - PAL
TV Tuner TV Tuner Card w/FM
Network Card 10/100 BaseT, Integrated
1394 Card IEEE-1394
Sound Azalia 7.1 Audio, Integrated on MB
Controller Realtek ALC880
Chassis Jaguar, 300B HV PSU
USB Interface Specification USB 2.0
External I/O Rear Connectors 4= USB, 1=1394, Parallel, 7.1 Audio, S/PDIF In & Out
External I/O Front Connectors 2= USB, 1= 1394, Microphone, Headphone, 9 in 1 Card
Reader w/USB
Expansion Slots (Total) 3= PCI, 1= PCI Express
Expansion Slots (FREE) 1= PCI
Drive Bays (Total) Two 5.25” external, One 3.5” external,
Two 3.5” internal
Drive Bays (FREE) One 5.25” external, One 3.5” internal
Keyboard/Mouse USB Wireless Internet command center; One-touch Internet
keyboard, Wireless optical scrolling mouse
Copyright Hewlett-Packard Co. 1994-2004
This information is subject to change without notice and
is provided "as is" with no warranty.
Hewlett-Packard shall not be liable for any direct,
indirect, special, incidental or consequential damages
in connection with the use of this material.
