Fabric OS v6.4.1 Release Notes v1.0 Page 17 of 62
Blade Support
Fabric OS v6.4 software is fully qualified and supports the blades for the 48000 platform noted in the
following table:
48000 Blade Support Matrix
48000 Blade Support Matrix48000 Blade Support Matrix
48000 Blade Support Matrix
(FC4-16, FC4-32, FC4-48), 16, 32 and 48-port
8Gbit blade (FC8-16, FC8-32, FC8-48), and the
6-port 10G FC blade (FC10-6)
Supported with any mix and up to 8 of each. No
restrictions around intermix. The 48000 must run Fabric
OS v6.0 or later to support the FC8-16 port blade and
Fabric OS v6.1 or later to support the FC8-32 and FC8-48
port blades.
Note:
Note:Note:
Note: FC8-64 is not supported on 48000.
Up to a total of 4 Intelligent blades (includes iSCSI,
FCIP/FCR and Application blade), FC4-16IP, FR4-18i, and
FA4-18 respectively. See below for intermix limitations,
exceptions, and a max of each blade.
Up to a maximum of 4 blades of this type.
Up to a maximum of 2 blades of this type. This can be
extended under special circumstances but must be
approved by Brocade’s Product Team. Up to 8 FR4-18i
blades can be installed if they are used only for FC
FastWrite or FCIP without routing.
Virtualization/Application Blade (FA4
Up to a maximum of 2 blades of this type.
(FX8-24), FCoE/CEE Blade (FCOE10-24)
Fabric OS v6.4 software is fully qualified and supports the blades for the DCX/DCX-4S noted in the following
table
:
DCX/DCX
DCX/DCXDCX/DCX
DCX/DCX-
--
-4S Blade Support Matrix
4S Blade Support Matrix 4S Blade Support Matrix
4S Blade Support Matrix
16, FC8-32, FC8-48, FC8-64) and the 6-port 10G
FC blade (FC10-6)
16, 32 and 48 port blades are supported with FOS v6.0
and above, 64 port blade is supported starting with FOS
v6.4.0, with any mix and up to 8/4 of each.
No restrictions around intermix.
Up to a total of 8/4 intelligent blades. See below for
maximum supported limits of each blade.
Up to a maximum of 4 blades of this type. This can be
extended under special circumstances, but must be
approved by Brocade’s Product Team. Up to 8 FR4-18i
blades can be installed in a DCX if they are used only for
FC FastWrite or FCIP without routing.
Virtualization/Application Blade (FA4
Up to a maximum of 4 blades of this type.
