18 Dell 8/4Gbps FC SAN 模块入门指南
53-1001963-01
FC SAN 模块连接至结构
以下操作前,请参阅第 14 页上的 “电缆布线指南”
行以下步骤,将 FC SAN 模块连接至结构。
1. 如需要安装 SFP 机,根据需要将其安装在外部光端口。
a. 移除要使用端口的防盖。
b. 如需要,移除 SFP 的端盖。
c. 整收机的方向,并将其牢固插入到端口上并使闩锁机件入到
有关特定类型机的说明,请参阅收制造商说明文件。
d. 根据需要,在剩余端口上重复子步骤 a b c
在此模块的外部端口上仅使用 Dell 认可的 SFP
2. 将光缆连接至收机。
该收发机采用锁定式设计,以确保正确定位。如安装收发机过程中遇到困难,确保其方向正确且已移除端盖。
注意
光缆弯曲半径不得小 5.08 厘米 / 2 英寸 (满拉伸负荷) 3.048 厘米 / 1.2 英寸 拉伸负荷)
于光纤易于过此推荐要对光进行缠绕
a. 整光缆连接的方向,使其齿式匙(连接器一上的突起)与收机上的插
b. 将光缆插入收机,闩锁机件入到。有关指光缆类型的说明,请参阅光缆制造商说明文件。
c. 根据需要,为余下的收机重此操作。
3. 检查 LED 指示灯状态,以验所有能是否正常
有关 LED 指示显示方的信息,请参阅 Dell 8/4Gbps FC SAN 模块硬件参考手册》中的章节 FC SAN
模块的操作”
4. 中输入 switchSho
w 命令,以验 FC SAN 模块是否正常运行。
此命令可提供 FC SAN 模块和端口状态的相关信息。
5. 中输入 fabricShow CLI 命令,验 FC SAN 模块在结构中是否确运行。
6. 输入 configUpload 命令,并按照提示将 FC SAN 模块配置备份 FTP 服务器。
此命令 FC SAN 模块配置上至服务器,使其需要的时至替代 FC SAN 模块。推荐定期备份
配置,以确保有完整的配置可供下至替代 FC SAN 模块。
有关如何备份配置的详细说明,请参阅 Dell 8/4Gbps FC SAN 模块管理员指南》
